The Future of Bone Surgery
When mectron introduced PIEZOSURGERY® in 2001, the technology was revolutionary for bone surgery. The device provided precision, safety, ergonomics and high quality performance for surgeons all around the world. This new technology became the benchmark for bone surgery devices.
In 2011, mectron raised the bar again with the PIEZOSURGERY® touch. Featuring an exclusive black glass touch screen, an intuitive user interface, and a rotatable LED handpiece, which provides a new level of ergonomics.
Get ready for selecting bone quality and irrigation flow rate at the touch of your finger – get ready for the PIEZOSURGERY® Touch.
Includes: 1 LED Handpiece, 1 K8 Wrench, 1 Carrying Case, 1 Surgical Tray,1 Sterilizable Infusion Set, 1 Foot Pedal, 1 Back-up Foot Pedal, 1 Touch Protective Film, 1 Year Warranty
Product Literature
Experience PIEZOSURGERY® (PDF)
PIEZOSURGERY® Insert Brochure (PDF)
Clinical Advantages
When it comes to cutting bone, the use of traditional burs and saws are an option. They do cut bone – but they do not differentiate: any soft tissue getting in the way can also be damaged.
The patented ultrasonic microvibrations of the original PIEZOSURGERY® cuts bone – and nothing else. No soft tissue is damaged, which allows you to work with a precision that facilitates not only surgery itself, but reduces postoperative discomfort for your patients at the same time.
Micrometric Cuts
PIEZOSURGERY® provides micrometric cuts for minimally invasive surgeries with maximum surgical precision and intra-operative tactile sensation.Selective Cuts
Selective cuts protects any kind of soft tissue. Nerves, vessels and membranes will not be injured while cutting bone. Thus, PIEZOSURGERY® offers maximum safety for surgeons and patients.
Cavitation Effect
PIEZOSURGERY® offers maximum intra-operative visibility. The cavitation effect of the ultrasonic movements lead to a blood-free surgical site.
Technical Specifications
Device compliant to Dir. 93/42/CEE:
Class II a
Classification as per EN 60601-1:
I
Applied part type B (handpiece, insert)
IP 20 (device)
IP X8 (foot pedal)
Device for intermittent operation:
60sec. ON - 30sec. OFF with irrigation
30sec. ON - 120sec. OFF without irrigation (ENDO,PERIO)
Power supply voltage:
100-240 Vac 50/60 Hz
Max. power absorbed:
120 VA
Fuses:
Type 5 x 20 mm T 2AL, 250V
Operating frequency:
Automatic scan
From 24 KHz to 36 KHz
Power types:
ENDO
PERIO
SPECIAL
CANCELLOUS
CORTICAL
IMPLANT
Peristaltic pump capacity:
Adjustable on the touch screen:
ENDO / PERIO - 7 flow levels: from 0 to 6
(from 0 to approximately 75ml/min)
SPECIAL / CANCELLOUS / CORTICAL / IMPLANT
6 capacity levels: from 1 to 6
(from 8 to approximately 75ml/min)
LED system of the handpiece:
Light function on AUTO: LED system of the handpieces
switches on as soon as the device starts to operate
and switches off 3 seconds after the foot pedal is released
Light function on ON: The LED of the handpiece is
always on; after 100 seconds of foot pedal disuse it
switches off by itself and the light function moves into position AUTO
Light Function on OFF: The LED of the handpiece is always off.
Protections of the APC circuit:
No handpiece detected
Cord interruption
Insert not tightened correctly or broken
Operating conditions:
from +10°C to +40°C
Relative humidity from 30% to 75%
Pressure of air P: 800hPa/1060hPa
Transport and storage conditions:
from -10°C to +70°C
Relative humidity from 10% to 90%
Pressure of air P: 500hPa/1060hPa
Peristaltic pump tube:
It is advisable not to exceed 8 sterilization cycles
Weight
7 lbs
Size
(L -W - H) 300 x 250 x 95 mm
