How the PIEZOSURGERY® GP supports your start.

Now this is as easy as it gets. If you are looking for a device which provides simplicity and clarity in every detail – here you are: 100% simple handling for utmost treatment security.

Materials specially selected for easy cleaning, disinfection and sterilization. Cost-effective standard parts for perfect economy.

You call that perfect for daily use. We call it PIEZOSURGERY® GP.

Includes 1 GP Handpiece, 1 K8 Wrench, 1 Carrying Case, 1 Surgical Tray, 1 Disposable Infusion Set, 1 Foot Pedal, 1 Year Warranty

Product Literature

Experience PIEZOSURGERY® (PDF)

PIEZOSURGERY® Insert Brochure (PDF)

Clinical Advantages

When it comes to cutting bone, the use of traditional burs and saws are an option. They do cut bone – but they do not differentiate: any soft tissue getting in the way can also be damaged.

The patented ultrasonic microvibrations of the original PIEZOSURGERY® cuts bone – and nothing else. No soft tissue is damaged, which allows you to work with a precision that facilitates not only surgery itself, but reduces postoperative discomfort for your patients at the same time.

Micrometric Cuts

PIEZOSURGERY® provides micrometric cuts for minimally invasive surgeries with maximum surgical precision and intra-operative tactile sensation.

Selective Cuts

Selective cuts protects any kind of soft tissue. Nerves, vessels and membranes will not be injured while cutting bone. Thus, PIEZOSURGERY® offers maximum safety for surgeons and patients.

Cavitation Effect

PIEZOSURGERY® offers maximum intra-operative visibility. The cavitation effect of the ultrasonic movements lead to a blood-free surgical site.

Technical Specifications

---

Device compliant to Dir. 93/42/CEE:

Class II a

---

Classification as per EN 60601-1:

I

Applied part type B (handpiece, insert)

IP 20 (device)

IP X8 (foot pedal)

---

Device for intermittent operation:

60sec. ON - 30sec. OFF with irrigation

30sec. ON - 120sec. OFF without irrigation (ENDO,PERIO)

---

Power supply voltage:

100-240 Vac 50/60 Hz

---

Max. power absorbed:

120 VA

---

Fuses:

Type 5 x 20 mm T 2AL, 250V

---

Operating frequency:

Automatic scan

From 24 KHz to 36 KHz

---

Power types:

ENDO

PERIO

SPECIAL

CANCELLOUS

CORTICAL

IMPLANT

---

Peristaltic pump capacity:

Adjustable on the touch screen:

ENDO / PERIO - 7 flow levels: from 0 to 6

(from 0 to approximately 75ml/min)

SPECIAL / CANCELLOUS / CORTICAL / IMPLANT

6 capacity levels: from 1 to 6

(from 8 to approximately 75ml/min)

---

LED system of the handpiece (optional):

LED system of the handpiece switches on as soon as the device starts to operate and switches off 3 seconds after the foot pedal is released

---

Protections of the APC circuit:

No handpiece detected

Cord interruption

Insert not tightened correctly or broken

---

Operating conditions:

from +10°C to +40°C

Relative humidity from 30% to 75%

Pressure of air P: 800hPa/1060hPa

---

Transport and storage conditions:

from -10°C to +70°C

Relative humidity from 10% to 90%

Pressure of air P: 500hPa/1060hPa

---

Peristaltic pump tube:

It is advisable not to exceed 8 sterilization cycles

---

Weight

7 lbs

---

Size

(L -W - H) 300 x 250 x 95 mm

---
